Mennekes AMAXX receptacle combination 930013
Product Name:AMAXX? receptacle combination
Part No.:930013.
Fitted with:1 CEE 32A, 5p, 400V
1 CEE 16A, 5p, 400V
2 SCHUKO? 16A, 230V.
Fusing:1 RCD 40A, 4p, 0.03A
1 MCB 32A, 3p, C
1 MCB 16A, 3p, C
2 MCB′s 16A, 1p, C.
Pre-fuse max.:40A.
InA:40A.
RDF:0.75.
Connection/feeder cable:for 1 cable up to 5 x 25 mm2.
Enclosure size:390 x 225 mm (H x W).
Protection type IP44.
pre-wired for installation.
hinged to the side.
enclosure and insert made of AMAPLAST.
fusing behind a transparent cover.

Mennekes AMAXX receptacle combination 940018
Product Name:AMAXX? receptacle combination
Part No.:930013SI.
Fitted with:1 CEE 32A, 5p, 400V
1 CEE 16A, 5p, 400V
2 SCHUKO? 16A, 230V.
Fusing:1 RCD 40A, 4p, 0.03A
1 MCB 32A, 3p, C
1 MCB 16A, 3p, C
2 MCB′s 16A, 1p, C.
Pre-fuse max.:40A.
InA:40A.
RDF:0.75.
Connection/feeder cable:for 1 cable up to 5 x 25 mm2.
Enclosure size:390 x 225 mm (H x W).
Protection type IP44.
pre-wired for installation.
hinged to the side.
enclosure and insert made of AMAPLAST.
fusing behind a transparent cover.

Mennekes AMAXX receptacle combination 930007
Product Name:AMAXX? receptacle combination
Part No.:930007.
Fitted with:1 CEE 32A, 5p, 400V
1 CEE 16A, 5p, 400V
2 SCHUKO? 16A, 230V.
Fusing:1 RCD 40A, 4p, 0.03A
1 Neozed D01, 3p
2 Neozed D01, 1p.
Pre-fuse max.:32A.
InA:32A.
RDF:0.85.
Connection/feeder cable:for 2 cable up to 5 x 25 mm2.
Enclosure size:390 x 225 mm (H x W).
Protection type IP44.
pre-wired for installation.
hinged to the side.
enclosure and insert made of AMAPLAST.
fusing behind a transparent cover.

Mennekes AMAXX receptacle combination 930010
Product Name:AMAXX? receptacle combination
Part No.:930010.
Fitted with:1 CEE 32A, 5p, 400V
1 CEE 16A, 5p, 400V
2 SCHUKO? 16A, 230V.
Fusing:1 MCB 32A, 3p, C
1 MCB 16A, 3p, C
2 MCB′s 16A, 1p, C.
Pre-fuse max.:63A.
InA:58A.
RDF:0.9.
Connection/feeder cable:for 2 cable up to 5 x 25 mm2.
Enclosure size:390 x 225 mm (H x W).
Protection type IP44.
pre-wired for installation.
hinged to the side.
enclosure and insert made of AMAPLAST.
fusing behind a transparent cover.

Mennekes AMAXXs receptacle combination 960011
Product Name:AMAXX?s receptacle combination
Part No.:960011.
Fitted with:1 CEE 32A, 5p, 400V
1 CEE 16A, 5p, 400V
2 SCHUKO? 16A, 230V.
Fusing:1 MCB 16A, 3p, C
1 MCB 16A, 3p, C.
Pre-fuse max.:32A.
InA:32A.
RDF:1.
Connection/feeder cable:for 1 cable up to 5 x 10 mm2.
Enclosure size:650 x 112.5 mm (H x W).
Protection type IP44.
pre-wired for installation.
enclosure and insert made of AMAPLAST.
fusing behind a transparent cover.

Mennekes AMAXX receptacle combination 930009
Product Name:AMAXX? receptacle combination
Part No.:930009.
Fitted with:1 CEE 32A, 5p, 400V
1 CEE 16A, 5p, 400V
2 SCHUKO? 16A, 230V.
Fusing:1 Neozed D02, 3p
1 Neozed D01, 3p
2 Neozed D01, 1p.
Pre-fuse max.:100A.
InA:45A.
RDF:0.7.
Connection/feeder cable:for 2 cable up to 5 x 25 mm2.
Enclosure size:390 x 225 mm (H x W).
Protection type IP44.
pre-wired for installation.
hinged to the side.
enclosure and insert made of AMAPLAST.
fusing behind a transparent cover.

Mennekes AMAXX receptacle combination 920025
Product Name:AMAXX? receptacle combination
Part No.:920025.
Fitted with:1 CEE 32A, 5p, 400V
1 CEE 16A, 5p, 400V
2 SCHUKO? 16A, 230V.
Connection/feeder cable:for 1 cable up to 5 x 10 mm2 and 1 cable up to 5 x 10 mm2.
Enclosure size:260 x 225 mm (H x W).
Protection type IP44.
pre-wired for installation.
enclosure and insert made of AMAPLAST.

Mennekes AMAXX receptacle combination 940006
Product Name:AMAXX? receptacle combination
Part No.:940006.
Fitted with:1 CEE 32A, 5p, 400V
1 CEE 16A, 5p, 400V
3 SCHUKO? 16A, 230V.
Fusing:1 RCD 63A, 4p, 0.03A
1 MCB 32A, 3p, C
1 MCB 16A, 3p, C
3 MCB′s 16A, 1p, C.
Pre-fuse max.:100A.
InA:45A.
RDF:0.7.
Connection/feeder cable:for 2 cable up to 5 x 25 mm2.
Enclosure size:520 x 225 mm (H x W).
Protection type IP44.
pre-wired for installation.
hinged to the side.
enclosure and insert made of AMAPLAST.
fusing behind a transparent cover.

Mennekes AMAXX receptacle combination 940005
Product Name:AMAXX? receptacle combination
Part No.:940005.
Fitted with:1 CEE 32A, 5p, 400V
1 CEE 16A, 5p, 400V
3 SCHUKO? 16A, 230V.
Fusing:1 RCD 63A, 4p, 0.03A
1 MCB 32A, 3p, C
1 MCB 16A, 3p, C
3 MCB′s 16A, 1p, C.
Pre-fuse max.:40A.
InA:40A.
RDF:0.8.
Connection/feeder cable:for 2 cable up to 5 x 25 mm2.
Enclosure size:520 x 225 mm (H x W).
Protection type IP44.
pre-wired for installation.
hinged to the side.
enclosure and insert made of AMAPLAST.
fusing behind a transparent cover.

Mennekes AMAXX receptacle combination 930008
Product Name:AMAXX? receptacle combination
Part No.:930008.
Fitted with:1 CEE 32A, 5p, 400V
1 CEE 16A, 5p, 400V
3 SCHUKO? 16A, 230V.
Fusing:1 RCD 40A, 4p, 0.03A
1 MCB 16A, 3p, C
3 MCB′s 16A, 1p, C.
Pre-fuse max.:32A.
InA:32A.
RDF:0.9.
Connection/feeder cable:for 2 cable up to 5 x 25 mm2.
Enclosure size:390 x 225 mm (H x W).
Protection type IP44.
pre-wired for installation.
hinged to the side.
enclosure and insert made of AMAPLAST.
fusing behind a transparent cover.

Mennekes AMAXX receptacle combination 930012
Product Name:AMAXX? receptacle combination
Part No.:930012.
Fitted with:1 CEE 32A, 5p, 400V
1 CEE 16A, 5p, 400V
3 SCHUKO? 16A, 230V.
Fusing:1 MCB 32A, 3p, D
1 MCB 16A, 3p, D
2 MCB′s 16A, 1p, C.
Pre-fuse max.:63A.
InA:54A.
RDF:0.85.
Connection/feeder cable:for 2 cable up to 5 x 25 mm2.
Enclosure size:390 x 225 mm (H x W).
Protection type IP44.
pre-wired for installation.
hinged to the side.
enclosure and insert made of AMAPLAST.
fusing behind a transparent cover.

Mennekes AMAXX receptacle combination 930011
Product Name:AMAXX? receptacle combination
Part No.:930011.
Fitted with:1 CEE 32A, 5p, 400V
1 CEE 16A, 5p, 400V
3 SCHUKO? 16A, 230V.
Fusing:1 MCB 32A, 3p,C
1 MCB 16A, 3p, C
2 MCB′s 16A, 1p, C
Pre-fuse max.:63A.
InA:54A.
RDF:0.85.
Connection/feeder cable:for 2 cable up to 5 x 25 mm2.
Enclosure size:390 x 225 mm (H x W).
Protection type IP44.
pre-wired for installation.
hinged to the side.
enclosure and insert made of AMAPLAST.
fusing behind a transparent cover.
